20 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Country of Origin | India |
| Type | Analogue Voltmeter (Moving Iron, Panel Mounting) |
| Standard | IS: 1248 / IEC 60051 |
| Click to view more | |
Product Details
System Voltage
240 V / 415 V AC (phase-to-neutral / phase-to-phase), other ranges on request
Size
96 × 96 mm and 72 × 72 mm (Square, DIN standard)
Measuring Range
Common ranges: 0–150 V, 0–300 V, 0–500 V, 0–600 V (custom ranges available)
Accuracy Class
Class 1.5 (standard) or Class 1.0 (optional)
Scale
Linear, 90° or 240° deflection, white background with black markings
Pointer
Knife-edge pointer, black
Case Construction
Moulded Polycarbonate / ABS plastic, flame-retardant
Mounting
Flush / Panel mounting with clamp
Terminal Connections
Screw type terminals at rear
Frequency
50 Hz ± 5%
Overload Capacity
1.2 × rated voltage (continuous), 2 × rated voltage (for 5 sec)
Insulation Class
Class B / E
Ambient Temperature
–10°C to +55°C
Service Conditions
Indoor, suitable for tropical climate
Dial Markings
As per IS: 1248 (Scale, Range, Accuracy Class, Manufacturer, Serial No.)
Protection
IP 20 (front) / higher on request
Routine Tests
As per IS: 1248 (Insulation, Accuracy, Deflection, Durability, etc.)
Options
Customized scale ranges (e.g., dual scale), square-root scale (if required)
